Thermal Expansion Tank
A thermal expansion tank is a small pressurized tank installed on the cold water supply line near your water heater. Its purpose is to absorb the excess water volume created when water heats up and expands. In a closed plumbing system (one with a check valve or pressure-reducing valve that prevents water from flowing back to the municipal supply), heated water has nowhere to expand. Without an expansion tank, this thermal expansion causes dangerous pressure spikes that can damage the water heater, fittings, and pipes. The tank contains a rubber diaphragm with air on one side and water on the other, as water expands, it pushes into the tank against the air cushion, safely absorbing the pressure increase.
💡 Key Takeaways
- ✓A thermal expansion tank is a small pressurized tank installed on the cold water supply line near your water heater. Its purpose is to absorb the excess water volume created when water heats up and expands. In a closed plumbing system (one with a check valve or pressure-reducing valve that prevents water from flowing back to the municipal supply), heated water has nowhere to expand. Without an expansion tank, this thermal expansion causes dangerous pressure spikes that can damage the water heater, fittings, and pipes. The tank contains a rubber diaphragm with air on one side and water on the other, as water expands, it pushes into the tank against the air cushion, safely absorbing the pressure increase.
- ✓Thermal expansion tanks are required by code in most jurisdictions whenever a closed plumbing system is present (check valve or PRV on the main line).
- ✓The tank's air pressure must match your home's incoming water pressure. A mismatch reduces the tank's effectiveness.
- ✓Expansion tanks typically last 5 to 10 years. A failed tank offers no protection and should be replaced promptly.
Thermal Expansion Tank
/ˈθɜːrməl ɪkˈspænʃən tæŋk/
Definition
A thermal expansion tank is a small pressurized tank installed on the cold water supply line near your water heater. Its purpose is to absorb the excess water volume created when water heats up and expands. In a closed plumbing system (one with a check valve or pressure-reducing valve that prevents water from flowing back to the municipal supply), heated water has nowhere to expand. Without an expansion tank, this thermal expansion causes dangerous pressure spikes that can damage the water heater, fittings, and pipes. The tank contains a rubber diaphragm with air on one side and water on the other, as water expands, it pushes into the tank against the air cushion, safely absorbing the pressure increase.
What does a thermal expansion tank do?
A thermal expansion tank absorbs the extra water volume created when your water heater heats water. It prevents dangerous pressure buildup in closed plumbing systems.
Source: The Cooling Company
Quick Facts
How Thermal Expansion Tank Works
The expansion tank absorbs excess pressure when water heats and expands.
Real-World Application
Many Las Vegas homes have pressure-reducing valves (PRVs) on the main water line, creating a closed system. When the water heater fires up, heated water expands with nowhere to go. Without an expansion tank, pressure can spike high enough to activate the temperature and pressure (T&P) relief valve, cause dripping faucets, or even damage the water heater tank over time.
Pro Tip
Check your expansion tank annually by tapping on it. The bottom half should sound hollow (air side) and the top should sound solid (water side). If the whole tank sounds waterlogged, the diaphragm has failed and the tank needs replacing.
“Check your expansion tank annually by tapping on it. The bottom half should sound hollow (air side) and the top should sound solid (water side). If the whole tank sounds waterlogged, the diaphragm has failed and the tank needs replacing.”
Important Things to Keep in Mind
- Thermal expansion tanks are required by code in most jurisdictions whenever a closed plumbing system is present (check valve or PRV on the main line).
- The tank's air pressure must match your home's incoming water pressure. A mismatch reduces the tank's effectiveness.
- Expansion tanks typically last 5 to 10 years. A failed tank offers no protection and should be replaced promptly.
Did You Know?
Water expands approximately 2% in volume when heated from 50°F to 120°F. In a 50-gallon water heater, that is roughly one gallon of extra water that needs somewhere to go.
FAQ
Do I need a thermal expansion tank?
Yes, if your home has a check valve or pressure-reducing valve on the main water line, creating a closed system. Most plumbing codes require one in these situations.
How do I know if my expansion tank has failed?
Tap the tank. If it sounds completely full of water (no hollow air sound at the bottom), the internal diaphragm has ruptured and the tank needs replacement.
What size expansion tank do I need?
Size depends on your water heater capacity and incoming water pressure. A 50-gallon heater typically needs a 2-gallon expansion tank, but your plumber can size it precisely.
